COMPASS – TSS MERIDIAN Gyro Compass – Survey version

thông itn

The Meridian gyrocompass product range is suitable for the ever-changing needs of a modern integrated navigation bridge system. This includes highly accurate performance with low cost of ownership and system flexibility. Due to the Meridian’s small size and fast settle time of less than 45 minutes, there are no limits to the type of vessel for which it is suitable.
The Meridian gyrocompass can be installed as a standalone unit or, together with any of the Meridian range of repeaters and ancillaries, it becomes a single, dual or triple gyro system. The Meridian can also be used to replace many existing gyrocompasses as a retrofit unit.

Performance:

Settle point error: 0.10° secant latitude
Settle point repeatability: 0.10° secant latitude
Static accuracy: 0.05° RMS secant latitude
Dynamic accuracy: 0.20° secant latitude

Data outputs
NMEA messages: GGA, GST, GSA, VTG, ZDA, GNS, GBS, RMC

Inputs Latitude Automatic -via RS232 or RS422, NMEA 0183 from GPS or manual
Speed Automatic -via RS232 or RS422, NMEA 0183 from log or pulse/contact closure at 100, 200
or 400/NM from log or manual
Compensation Latitude 80°N to 80°S
Speed 0-90 knots
Environmental Ambient operating temperature 0°C – 45°C (–15°C – +55°C with reduced accuracy)
Storage temperature –25°C – +80°C
Gimbal limits ±45° roll and pitch
Mean time between failures (MTBF) >30,000 hours (calculated); >100,000 hours (in service data)
Shock(survival) 10g
Operating Voltage Input voltage 24Vdc (19-36Vdc)
Power Start-up >3A at switch on / <1.5A in ready mode
Dimensions Size 344mm (h) x 267mm (w) x 440mm (d)
Weight 15.5 Kg
Accessories Included Operator handbook,spare fuse Operator manual, transit case,spare connector
Optional Remote control unit,various repeaters and accessories
Standards IMO A424(X1), IMO A821(19), IEC 60945, ISO 8728, ISO 16328, IEC 62288,Marine Equipment Directive
96/98/EC
